NORMTOR Full Vision — The Sectional Door That Works as a Display Window

NORMTOR Full Vision — the fully-transparent sectional door that does not cover the display when closed and leaves the area completely free when opened. Specifically designed for car galleries, showrooms, premium retail and commercial entrance areas.

Should your customer be able to see what is inside even when the door is closed? If the answer is yes: NORMTOR Full Vision.

Why Full Vision?

A standard sectional door is focused on insulation, security and resistance — its surface is opaque. But in a car gallery, in a showroom, or in an open-fronted café, visibility is a value in itself. The passing tourist or potential customer should see the product inside; the showcase effect is part of brand communication.

This is exactly where Full Vision steps in: thanks to the plexiglass infill placed inside an aluminium frame, the door functions like a display window even when closed.

Technical summary — at a glance

Feature	Value
Frame	Aluminium, 1.3 mm thickness
Infill	3 mm plexiglass
Maximum size	5,000 × 6,000 mm
Motor	Selected for door weight, usage and configuration
Variant	Single-sheet plexiglass in the cited specification
Conformity	Documents matched to the proposed configuration

Application requirements

Full Vision can be considered for vehicle showrooms, service entrances or openings needing visibility. Assess clear passage, moving-leaf space, pedestrian traffic and infill requirements together.

A transparent leaf does not establish suitability for every shop or café entrance. Pedestrian passage, escape requirements, climate separation and controls need assessment for the complete proposed configuration.

Infill and thermal requirements

The cited Full Vision specification describes 3 mm single-sheet plexiglass in an aluminium frame. It does not document a double-skin variant or a thermal-transmittance value for the complete door. The transparent infill serves the visibility requirement; its thermal performance should not be inferred from an industrial sandwich panel.

Where insulation is a project requirement, the proposed infill and complete-door configuration require their own documented performance. Current options and supporting documents can be requested from our sales team.

Certification

Full Vision conformity documents must belong to the same aluminium-frame, infill, dimensions, hardware and motor configuration being proposed. The SP Class 3 wind / Class 2 air-permeability result for an industrial panel-door specimen does not automatically apply to Full Vision. The scope and validity dates of the CE declaration and any EAC or Domestic Product documents are verified separately at quotation stage.

Motor and automation

The motor, control board and safety devices are selected together for the door weight, dimensions and usage frequency. The cited specification does not establish r-tec 10024 as the standard motor for every Full Vision configuration. The proposed drive, remote control, photocell and flasher must be checked as a compatible project package.

Order and quotation

For detailed product specifications, available configurations and delivery time, please use our contact form. Opening dimensions and project information allow preparation of a quotation; the on-site survey is carried out by the authorised technical team responsible for your project.

Product page: Products > Sectional Doors > NORMTOR Full Vision Quick contact: contact form
