1Key technical specifications
The most critical technical parameters of this product.
- Mains voltage 220 VAC (±10%)
- Pulling force (class) 1,000 N
- Installation type Ceiling-mounted rail drive
- Target door type Garage door; verify model suitability for the project
- Drive type Chain drive on rail
- Display LED display
Show all technical specifications (10)
Accessory
| Feature | Value |
|---|---|
| Lighting | Automatic lighting |
Safety
| Feature | Value |
|---|---|
| Emergency release | Manual mode |
Control
| Feature | Value |
|---|---|
| Remote control | 433.92 MHz rolling code |
Performance
| Feature | Value |
|---|---|
| Soft start / stop | Available |
Videos
Installation and support guides
These videos demonstrate the model and control board shown. They may provide general reference for other products; use the current technical manual for the relevant model for connections and settings.
PULL1000 garage door motor 5 videos
Motor overview, limits, photocell, remote controls and external receiver connections.
For installations using PULL1000; do not assume the same settings for PULL1200/PULL1200L.
Turkish video archive from the Alkur YouTube channel; titles and topic notes are translated.
Related product guide
An overview of the PULL1000 garage door motor control board and programming features.
- 2:30 Watch on YouTube
An overview of the PULL1000 garage door motor control board and programming features.
- 1:20 Watch on YouTube
A guide to connecting a safety photocell to the PULL1000 garage door motor.
- 2:00 Watch on YouTube
A demonstration of programming garage door opening and closing limits on the PULL1000 motor.
- 0:43 Watch on YouTube
A guide to pairing remote controls and clearing stored remotes on the PULL1000 motor.
- 1:58 Watch on YouTube
A demonstration of connecting an external remote-control receiver to the PULL1000 garage door motor.
Overview
PULL1000 is a ceiling-mounted garage door motor with a rail, rated in the 1,000 N pulling-force class. On spring-balanced doors, the balancing mechanism supports the load while the motor provides opening and closing motion. Verify the balancing type, door dimensions and selected rail before installation.
1,000 N pulling force — what does it mean?
1,000 N is the documented motor pulling-force class; it cannot be converted directly into door mass or a permitted door-weight rating. Check door dimensions, spring balance and the selected rail arrangement before installation.
LED display and documented settings
The PULL1000 technical PDF says operating status appears on an LED display. It documents these programming steps:
- Open and close limits (P1): Save positions with the SET, UP and DOWN buttons.
- Force adjustment (P2): Choose from levels F1–F9.
- Safety photocell (P3): Enable or disable the optional photocell function.
- Automatic closing (P4): B0 is off; the documented B1–B9 waits are 5, 15, 25, 30, 40, 50, 55, 65 and 70 seconds.
- Lock and remote control: The manual describes lock settings and rolling-code remote learning/erasing separately.
The manuals describe automatic lighting during opening and closing. The Turkish manual page 2 says it switches off after 3 seconds, while the full English manual page 2 says three minutes. No definite duration is given without confirming the current model revision.
Target projects
- Residential individual garage door
- Apartment shared garage entrance
- Villa garage door (spring-balanced sectional)
- Estate internal pedestrian + vehicle combined garage
- Estate basement car park entrance gate (in limited situations — if size/load is suitable)
Field checks
- Initial check: Page 3 of the technical PDF directs the installer to switch to manual mode, push and pull the door, and confirm the carriage moves along the rail.
- Programming: Follow the model manual’s button sequence for limits, force, photocell, automatic closing, lock and remote control.
- Drive chain: Page 10 of the PDF describes checking slack and the M8 nut when the chain is noisy. Service should follow current manufacturer instructions.
Check door dimensions, spring balance and the selected rail arrangement before installation. This PDF states no maximum door height or door-weight class; confirm suitability against the current installation drawing.
In which sectors is it used?
This product family is preferred in the sectors and application areas below.
- House and villa garage
- Residential complex car park
Frequently Asked Questions
Below we've compiled the most common questions and answers regarding this product.
-
The PULL 1000 garage door motor runs noisily or with a rattling chain?
The troubleshooting table on page 10 lists a loose chain as a possible cause of chain noise and refers to the M8 nut. It gives no precise tension amount or definitive diagnosis; an authorised service team should assess the installation against the current manual.
-
On the PULL 1000 the wall button works but the remote control does not?
The PULL 1000 troubleshooting table lists lock mode, an unpaired transmitter and a flat transmitter battery as possible causes. Check these against the model guide. If the fault remains, ask the authorised technical team to diagnose it rather than ruling out the board or motor remotely. Check the battery when range becomes short.
